Mazda2 Specifications

Print Specifications

Hatch

Hatch

powertrain

powertrain	Neo	Maxx	Genki
Engine type	1.5 litre in-line 4 cylinder 16 valve DOHC S-VT	1.5 litre in-line 4 cylinder 16 valve DOHC S-VT	1.5 litre in-line 4 cylinder 16 valve DOHC S-VT
Engine capacity	1,498 cc	1,498 cc	1,498 cc
Bore and stroke	78.0 mm x 78.4 mm	78.0 mm x 78.4 mm	78.0 mm x 78.4 mm
Compression ratio	10.0 : 1	10.0 : 1	10.0 : 1
Maximum power	76 kW @ 6,000 rpm	76 kW @ 6,000 rpm	76 kW @ 6,000 rpm
Maximum torque	135 Nm @ 4,000 rpm	135 Nm @ 4,000 rpm	135 Nm @ 4,000 rpm
Throttle control	Electronic (drive-by-wire)	Electronic (drive-by-wire)	Electronic (drive-by-wire)
Fuel system	Electronic fuel injection	Electronic fuel injection	Electronic fuel injection
Fuel tank capacity	42 litres	42 litres	42 litres
Recommended fuel	Unleaded or E10 (91RON or higher)	Unleaded or E10 (91RON or higher)	Unleaded or E10 (91RON or higher)
Fuel consumption man (combined)¹	6.4 litres per 100km	6.4 litres per 100km	6.4 litres per 100km
Fuel consumption auto (combined)¹	6.8 litres per 100km	6.8 litres per 100km	6.8 litres per 100km
Emissions standard	Euro stage IV	Euro stage IV	Euro stage IV
Manual transmission	5-speed	5-speed	5-speed
Automatic transmission	4-speed	4-speed	4-speed
Gear ratio 1st - man/auto	3.416 / 2.816	3.416 / 2.816	3.416 / 2.816
Gear ratio 2nd	1.842 / 1.553	1.842 / 1.553	1.842 / 1.553
Gear ratio 3rd	1.290 / 1.000	1.290 / 1.000	1.290 / 1.000
Gear ratio 4th	0.972 / 0.695	0.972 / 0.695	0.972 / 0.695
Gear ratio 5th	0.775 / -	0.775 / -	0.775 / -
Gear ratio reverse	3.214 / 2.279	3.214 / 2.279	3.214 / 2.279
Gear ratio final drive	4.105 / 4.147	4.105 / 4.147	4.105 / 4.147

chassis

chassis	Neo	Maxx	Genki
Brake type front	Ventilated disc	Ventilated disc	Ventilated disc
Brake type rear	Drum	Drum	Drum
Steering type	Electric power assist steering	Electric power assist steering	Electric power assist steering
Steering wheel turns lock to lock	2.7	2.7	2.7
Suspension front	MacPherson strut	MacPherson strut	MacPherson strut
Suspension rear	Torsion beam	Torsion beam	Torsion beam
Turning circle kerb to kerb	9.8 m	9.8 m	9.8 m
Tyre size	185/55R15 82V	185/55R15 82V	195/45R16 80W
Wheel size	15 x 6.0 J	15 x 6.0 J	16 x 6.5 J
Wheel type	Steel	Alloy	Alloy
Wheel type (spare)	Temporary	Temporary	Temporary

exterior

exterior	Neo	Maxx	Genki
Door handles (body coloured)
Exhaust extension (chrome)	-	-
Fog-lamps (front)	-	-
Front and rear bumpers (body coloured)
Front centre roof mounted aerial
Green-tinted windscreen, side and rear windows
Headlamps (Halogen)
Metallic/Mica paint	No cost option	No cost option	No cost option
Mudflaps (front and rear)			-
Power mirrors (body coloured)
Power windows
Rear spoiler	-
Side skirts	-	-

interior

interior	Neo	Maxx	Genki
12 volt power outlet
Air-conditioning			-
Air-conditioning (climate control)	-	-
Ambient temperature display	-	-
Cruise control
Cupholders
Digital clock
Door ajar warning light
Door map pockets (front)
Driver's left footrest
Glove box with magazine rack
Headlamps auto on/off function	-	-
Illuminated entry system with delayed fade
Instrument panel light dimmer
Interior illumination: cargo room lamp
Interior illumination: dome lamp
Interior release for fuel filler door
Leather-wrapped: gear shift knob	-	-	manual only
Leather-wrapped: steering wheel	-	-
Lights-left-on audible warning
Low fuel warning light
Passenger assist grip (front)
Rear console tray
Seat trim: cloth
Seats (front) with: adjustable head restraints
Seats (front) with: height adjustment (driver)
Seats (front) with: rake and slide adjustment
Seats (rear) with: 60/40 split fold backrest
Seats (rear) with: adjustable head restraints
Tachometer and electronic odometer/tripmeter
Tilt adjustable steering wheel
Trip computer (current and average fuel consumption, distance to empty and average vehicle speed)	-	-
Vanity mirrors (front)
Ventilation pollen filter
Window demister (rear)
Wipers (front) 2-speed with intermittent function			-
Wipers (front) 2-speed with rain-sensing function	-	-
Wiper (rear) with intermittent function

audio

audio	Neo	Maxx	Genki
AM/FM tuner
Auxiliary input (3.5mm MP3 player compatible)
CD player, single disc (MP3 compatible)
Speakers, number of	4	4	4
Steering wheel mounted audio controls
USB input (iPod® compatible)

safety

safety	Neo	Maxx	Genki
Airbags SRS: front (driver and passenger)
Airbags SRS: curtain (front and rear)
Airbags SRS: side (front)
Anti-lock Braking System (ABS)
Child restraint anchor points and childproof rear door locks
Collapsible steering column
Dynamic Stability Control (DSC) - switchable on/off
Electronic Brake-force Distribution (EBD)
Emergency Brake Assist (EBA)
Engine immobiliser
High mount stop lamp
Intrusion-minimising brake pedal
Left-hand-side convex (wide angle) exterior mirror
One touch (up and down) power window (driver)
Remote central locking
Seat-belt warning audible and visual (front)
Seat-belts 3-point lap-sash (all seats)
Seat-belts (front) with pretensioners, load-limiters and height adjustable shoulder anchorages
Side impact door beams
Traction Control System (TCS)
'Triple H' safety construction with front and rear crumple zones
Whiplash-minimising front seats

dimensions

dimensions	Neo	Maxx	Genki
Ground clearance laden	119 mm	119 mm	119 mm
Overall height	1,475 mm	1,475 mm	1,475 mm
Overall length	3,900 mm	3,900 mm	3,900 mm
Overall width	1,695 mm	1,695 mm	1,695 mm
Track front	1,475 mm	1,475 mm	1,465 mm
Track rear	1,465 mm	1,465 mm	1,455 mm
Wheelbase	2,490 mm	2,490 mm	2,490 mm

weights and capacities

weights and capacities	Neo	Maxx	Genki
Cargo room volume (VDA)²	469 litres	469 litres	469 litres
Cargo room volume (VDA)³	250 litres	250 litres	250 litres
Kerb weight man	1,010 kg	1,010 kg	1,016 kg
Kerb weight auto	1,032 kg	1,032 kg	1,038 kg
Towing capacity braked⁴	700 kg	700 kg	700 kg
Towing capacity unbraked⁴	500 kg	500 kg	500 kg
Towball download maximum	70 kg	70 kg	70 kg
